| Specifications |
| Operating Manual |
- Clear and simple navigation
- 36 languages - Not available with Edge browser - use Chrome, Firefox, Opera or Safari browser.
- Quick 1 minute demonstration videos to show how to set the functions.
- Designed for easy use on Android, iPhone and desktops / laptops.
- Quick to load, low data usage, no special software needed.
 Operating manual ...
|
| Input Signals | All measurements are computed with 32 bit floating point calculations for the ultimate in precision and flexibility in scaling.
Self-locking, if left unattended, to help prevent accidental or unauthorised changes of settings.
The standard meter, out of its box, accepts these signals:
- Load Cell 4 or 6 wire, with cabling diagnostics. Accepts Zener barriers in series.
- 4-20mA, 2 wire, 3 wire and 4 wire with input protecton against overload.
- -20 to + 20V DC
- DC current shunts: 0-50mV, 0-60mV, 0-75mV, 0-100mV.
- Thermocouples Type B,E,J,K,N,R,S,T with local or remote fixed CJ compensation
Deg. C, F, K and Rankine
0.1 or 1.0 degree resolution
- PT100, 2 wire, 3 wire and 4 wire
Deg. C, F, K and Rankine
0.1 or 1.0 degree resolution
- Wheatstone bridge pressure sensors 20mV, 50mV, 100mV
- Potentiometer position / angle transducer, 3 wire and 4 wire.
- Low value resistance, 1 Ohm FSD up to 1000 Ohm FSD. 2 wire and 4 wire connection
- NPN / Contact closure pulse totaliser.
- NPN / Contact closure production rate meter with flexible averaging.
- Elapsed timer, with start, stop, reset
It only takes a couple of button presses to select a mode. All settings are lockable.
Optional functions:
- Real time clock HH:MM:SS and calendar, days since last accident
- Precision power frequency monitoring 40.000 to 70.000 Hz.
- RS232 slave mode
- RS485 slave mode
31 point post-scaling lineariser - easy editing, can turn off and on for easy comparisons.
Detachable high quality screw terminal connectors for easy installation and maintenance.
|
| Display |
- 6 digits high brightness LED
- 3 colours, red, green, yellow
- Adjustable Brightness for use in direct sunlight or at night.
- Leading zero blanking for maximum clarity
- Digit height 14.2mm , clearly legible up to 7m away.
Also available in fully sealed, indoor and outdoor mounting large digit formats:
Digit heights 57mm, 102mm, 150mm, 200mm, 300mm, 400mm.
|
| Dimensions |
- 1/8 DIN 96mm wide x 48mm high bezel - industry standard.
- Cutout = 92mm wide x 45mm high
- Depth beghind panel 125mm
- Weight (no options fitted) = XXX grammes
- Weight (all options fitted) = YYY grammes
- Sealing: IP65 as standard, IP67 with optional front cover.
|
| Power |
- AC Version: 95-265 V AC, 40-70 Hz
- DC Version: 11-30V DC
- Detachable high quality screw terminal connectors.
|
| Alarm output options |
- Quick plug-in installation
- 4 x SPCO mechanical, rated 2A, 250V, gold plated contacts for high reliability.
- 4 x AC solid state, rated 2A, 250V
- 4 x DC solid state, rated 2A, 60V
- 10 different alarm and control functions with timers.
- Alarms can change the display colour.
- Detachable high quality screw terminal connectors.
|
| Analog output options |
- Quick plug-in installation
- 4-20mA high precision, isolated, fully scaleable. Active and passive.
- 0-10V high precision, isolated, fully scaleable
- Direct or inverse scaling
- Precision: +/- 0.025% of range
- Detachable high quality screw terminal connectors.
|
| Comms Port Options |
- Quick plug-in installation
- 2 isolated ports available
- RS232 or RS485, ASCII or Modbus format
- Addressable or streaming outputs
- Detachable high quality screw terminal connectors.
|
| 6 x Logic Input Ports | Configurable logic input ports:
Accept NPN or contact closure inputs.
- Hold - freezes display and all outputs
- Tare - subtracts any offset.
- Reset - clears min and max memory, tare memory and latches.
- Start Timer
- Stop Timer
- Reset Timer
- Display Peak - shows maximum reading since last reset
- Display Valley - shows minimum reading since last reset
- Display Nett
- Display Gross
- Display Tare Amount
- Display meter's temperature -
- Mirror display (heads-up mode)
- Detachable high quality screw terminal connectors.
|
