Good news for distributors!
If you want fast moving stock, you need the new INT5 digital panel meter controller! Designed especially for distribution, it combines most common meter funtions into one user friendly, versatile package.
Distributor of digital panel meters


The INT5 makes stock control easy, and your customers will love its simple, fast setup method and clear, multi-language manual!

One meter, all these measurements! Temperature, total, RPM, frequency, weight, torque, pressure, time, elapsed time, resistance, current, position...

Suits all process industries with just one user-friendly model.

Dust won't collect on this product, you customers will make sure of that!...



A selection of many different display types

Combine the functions of many meter types into one versatile meter...
Your value-added team can quickly re-purpose one meter into one of many different functions. Simplify the setup process ...
Result: One versatile, easy-to-use, easy to sell precision model!

The INT5 high performance digital panel meter


One high-performance, economical, easy-to-use meter, ideal for most process measurement or control applications.

Introducing the all new INT5 digital panel meter!

One meter replaces a whole shelf of traditional meters AND we guarantee it is easier to set up than any of them!

This amazing new meter makes the whole supply chain happy!

Your sales teams will be delighted with the flow of orders from happy customers. Your tech support teams will be delighted with the ease-of use and clarity of information. Your customers will be delighted with the performance, ease of use and versatility of this amazing new meter.

And of course, they will be impressed with the speed of delivery, as your stock planning will be so much simpler, with just one meter to cover so many applications!

Designed and built in England with 3 year warranty.

Tell your colleagues about the INT5 and keep the whole supply chain happy!

Share this page:      Share on WhatsApp    Share on LinkedIn       Share on Facebook


Contact us today for full details and pricing.


London Electronics Ltd ::: Designers and Manufacturers
Thorncote Road, Near Sandy, Bedfordshire, ENGLAND SG19 1PU
sales@london-electronics.com Tel. +44 (1767) 626444
London Electronics Ltd logo


Specifications
Operating Manual
  • Clear and simple navigation
  • 36 languages - Not available with Edge browser - use Chrome, Firefox, Opera or Safari browser.
  • Quick 1 minute demonstration videos to show how to set the functions.
  • Designed for easy use on Android, iPhone and desktops / laptops.
  • Quick to load, low data usage, no special software needed.
INT5 digital panel meter user friendly instructions and manual Operating manual ...
Input SignalsAll measurements are computed with 32 bit floating point calculations for the ultimate in precision and flexibility in scaling.

Self-locking, if left unattended, to help prevent accidental or unauthorised changes of settings.

The standard meter, out of its box, accepts these signals:
  • Load Cell 4 or 6 wire, with cabling diagnostics. Accepts Zener barriers in series.
  • 4-20mA, 2 wire, 3 wire and 4 wire with input protecton against overload.
  • -20 to + 20V DC
  • DC current shunts: 0-50mV, 0-60mV, 0-75mV, 0-100mV.
  • Thermocouples Type B,E,J,K,N,R,S,T with local or remote fixed CJ compensation
    Deg. C, F, K and Rankine
    0.1 or 1.0 degree resolution
  • PT100, 2 wire, 3 wire and 4 wire
    Deg. C, F, K and Rankine
    0.1 or 1.0 degree resolution
  • Wheatstone bridge pressure sensors 20mV, 50mV, 100mV
  • Potentiometer position / angle transducer, 3 wire and 4 wire.
  • Low value resistance, 1 Ohm FSD up to 1000 Ohm FSD. 2 wire and 4 wire connection
  • NPN / Contact closure pulse totaliser.
  • NPN / Contact closure production rate meter with flexible averaging.
  • Elapsed timer, with start, stop, reset
It only takes a couple of button presses to select a mode. All settings are lockable.


Optional functions:
  • Real time clock HH:MM:SS and calendar, days since last accident
  • Precision power frequency monitoring 40.000 to 70.000 Hz.
  • RS232 slave mode
  • RS485 slave mode

31 point post-scaling lineariser - easy editing, can turn off and on for easy comparisons.

Detachable high quality screw terminal connectors for easy installation and maintenance.
Display
  • 6 digits high brightness LED
  • 3 colours, red, green, yellow
  • Adjustable Brightness for use in direct sunlight or at night.
  • Leading zero blanking for maximum clarity
  • Digit height 14.2mm , clearly legible up to 7m away.
Also available in fully sealed, indoor and outdoor mounting large digit formats:
Digit heights 57mm, 102mm, 150mm, 200mm, 300mm, 400mm.
Dimensions
  • 1/8 DIN 96mm wide x 48mm high bezel - industry standard.
  • Cutout = 92mm wide x 45mm high
  • Depth beghind panel 125mm
  • Weight (no options fitted) = XXX grammes
  • Weight (all options fitted) = YYY grammes
  • Sealing: IP65 as standard, IP67 with optional front cover.
Power
  • AC Version: 95-265 V AC, 40-70 Hz
  • DC Version: 11-30V DC
  • Detachable high quality screw terminal connectors.
Alarm output options
  • Quick plug-in installation
  • 4 x SPCO mechanical, rated 2A, 250V, gold plated contacts for high reliability.
  • 4 x AC solid state, rated 2A, 250V
  • 4 x DC solid state, rated 2A, 60V
  • 10 different alarm and control functions with timers.
  • Alarms can change the display colour.
  • Detachable high quality screw terminal connectors.
Analog output options
  • Quick plug-in installation
  • 4-20mA high precision, isolated, fully scaleable. Active and passive.
  • 0-10V high precision, isolated, fully scaleable
  • Direct or inverse scaling
  • Precision: +/- 0.025% of range
  • Detachable high quality screw terminal connectors.
Comms Port Options
  • Quick plug-in installation
  • 2 isolated ports available
  • RS232 or RS485, ASCII or Modbus format
  • Addressable or streaming outputs
  • Detachable high quality screw terminal connectors.
6 x Logic Input PortsConfigurable logic input ports:
Accept NPN or contact closure inputs.
  • Hold - freezes display and all outputs
  • Tare - subtracts any offset.
  • Reset - clears min and max memory, tare memory and latches.
  • Start Timer
  • Stop Timer
  • Reset Timer
  • Display Peak - shows maximum reading since last reset
  • Display Valley - shows minimum reading since last reset
  • Display Nett
  • Display Gross
  • Display Tare Amount
  • Display meter's temperature -
  • Mirror display (heads-up mode)
  • Detachable high quality screw terminal connectors.



Contact us today for full details and pricing.


London Electronics Ltd ::: Designers and Manufacturers
Thorncote Road, Near Sandy, Bedfordshire, ENGLAND SG19 1PU
sales@london-electronics.com Tel. +44 (1767) 626444
London Electronics Ltd logo


See how easy this meter is to use...

All videos are visual only - you don't need sound enabled.

We did this because engineers often work in noisy environments and wear ear defenders.

Another benefit is that the videos are suitable for anyone, speaking any language.


First, how to select the main function of the meter - whether it is to be a weighing display or a temperature display or a totaliser or a timer etc. There are 21 functions available.

In the video, the functions you will see are:
Totaliser, Rate meter, Clock, Elapsed timer up or down, Power Frequency display, DC Shunt, 0-10V, 4-20mA, Load Cell, RTD.A, RTD.B, 3 wire potentiometer, 4 wire resistance meter, Thermocouple types B,E,J,K,N,R,S,T.

Main meter function...

Quick and Easy


How to select the main colour of the display. The display must be unlocked, shown by the flashing 'lock' LED ...

Colour selection...

Quick and Easy


How to select the brightness of the display. The display can be locked, so can have its brightness adjusted at any time ...

Brightness adjustment...

Quick and Easy



Contact us today for full details and pricing.


London Electronics Ltd ::: Designers and Manufacturers
Thorncote Road, Near Sandy, Bedfordshire, ENGLAND SG19 1PU
sales@london-electronics.com Tel. +44 (1767) 626444
London Electronics Ltd logo


Mechanical details of the new INT5




Front quarter of INT5 digital panel meter

Rear quarter of INT5 digital panel meter



Rear view connector identies for INT5 digital panel meter

1Analog signal inputs and sensor power output
2Logic signal inputs
3Power input
4Isolated analog output
5Data port 1
6Data port 2
7Alarm relay 1
8Alarm relay 2
9Alarm relay 3
10Alarm relay 4
